Complete steel detailing, from anchor bolts to handrail
One detailing partner for the full structural and miscellaneous steel package. We work from your contract documents, resolve conflicts before they reach the shop floor, and deliver files your fabrication software reads directly.
Structural Steel Shop Drawings
Fully dimensioned assembly and single-part drawings for beams, columns, braces, and trusses, ready for the saw, the drill line, and the fit-up table.
3D Modeling & BIM Coordination
Fully coordinated 3D models in Tekla, SDS/2 or Advance Steel, with IFC and Revit-compatible exports so the design team can coordinate against MEP and architecture before fabrication starts.
Erection Drawings & Anchor Bolt Plans
Erection plans, elevations, and sections that show the crew exactly where every piece goes, plus anchor bolt layouts the concrete sub can set right the first time.
BIM & Revit Coordination
BIM-ready files and Revit-compatible models that integrate into your project's coordination workflow.
CNC & Fabrication Files
DXF and NC files formatted for CNC machinery.
Material Takeoffs & ABMs
Advanced bills of material and takeoffs generated straight from the model, so purchasing, nesting, and estimating all work from the same numbers. KISS files, .EJE, and bolt lists are available based on your needs.
Submit Plans
Send us your plans for a bid
Upload your structural drawings and specs, or email them directly. We’ll review the scope, ask what we need to, and return a clear, itemized proposal with a committed schedule.
Add your files. Drop drawings, specs, and models in the box, or browse to select them.
Tell us about the job. Name, company, email, project name, and any notes.
Send plans. Press Send Plans and your files come straight to us. Plan sets over 18 MB get one quick extra step: a secure Dropbox upload.
Why Mountain View
Detailing that keeps your shop moving
Mountain View Steel Detailing produces shop drawings, erection drawings, and 3D models for fabricators, erectors, general contractors, and engineers. Every connection is modeled, every sheet is checked, and every package ships on the date we committed to, so your shop cuts steel instead of writing RFIs.
Bad drawings cost far more than the detailing fee: shop rework, field fixes, back charges, and a schedule that slips week by week. For more than 30 years, we've built our practice on getting it right before it ships.
Capabilities
The tools, standards, and capacity behind every package
We detail in AutoCAD, Advance Steel, Tekla Structures, and SDS/2, and deliver in the formats your shop and design team already use. No conversion headaches, no re-keying data.
